Application:
Railway, vehicle, traffic system project, air-condition. Various machine tool and machines. Automatic control equipment and electric power plants. Petroleum, chemical industry. Transmission and distribution system, communication system, base station.
| Type | Trade Size | I.D. (mm) | O.D. (mm) | Meter/Coi | ||
| Min. | Max. | Min. | Max. | |||
| CH-HLC-001 | 1/4" | 9 | 9.6 | 13 | 13.5 | 50 |
| CH-HLC-002 | 3/8" | 12.3 | 12.8 | 17.5 | 18 | 50 |
| CH-HLC-003 | 1/2" | 15.8 | 16.3 | 20.8 | 21.5 | 50 |
| CH-HLC-004 | 3/4" | 20.8 | 21.3 | 26.1 | 26.7 | 30 |
| CH-HLC-005 | 1" | 26 | 27 | 32.8 | 33.4 | 30 |
| CH-HLC-006 | 1-1/4" | 34.8 | 35.5 | 41.4 | 42.2 | 30 |
| CH-HLC-007 | 1-1/2" | 39.8 | 40.5 | 47.4 | 48.3 | 30 |
| CH-HLC-008 | 2" | 50.8 | 51.5 | 59.4 | 60.3 | 10 |
| CH-HLC-009 | 2-1/2" | 63 | 64.3 | 72.1 | 73 | 10 |
| CH-HLC-010 | 3" | 78.6 | 79.3 | 87.5 | 88.5 | 10 |
| CH-HLC-011 | 4" | 110.6 | 101.6 | 111.5 | 112.5 | 5 |
Buyer RFQ questions
These questions help OEM buyers, distributors, project contractors and procurement teams specify liquid tight flexible conduit before sample review and bulk quotation.
Liquid tight conduit is used to protect wires and cables when moisture, oil, dust, vibration or movement may affect the installation. Typical uses include machinery wiring, HVAC equipment, outdoor lighting, control cabinets, traffic systems, vehicles and industrial project assemblies.
A useful RFQ should include trade size, ID and OD range, conduit length, jacket or coating requirement, connector style, thread standard, bend requirement, working environment, sample quantity, bulk order quantity and target delivery market.
The conduit size should match cable space, bend radius, installation route and equipment entry points. The connector should match conduit diameter, thread type, sealing requirement, installation angle, material, finish and the final enclosure or machine interface.
Yes. Liquid tight conduit can be reviewed by size, jacket material, length, connector match, packaging and project documentation needs. Drawings, samples or installation photos help confirm the specification before quotation.
Yes. Samples help buyers confirm conduit size, flexibility, connector fit, sealing feel, surface finish, cable clearance, packaging and installation compatibility before moving into bulk production.
